CANON EOS C400 CAMERA BODY

Update juni 2024
EOS C400 er et helt nyt kamera fra CANON.

Endelig kom det kamera vi har ventet på! Canon EOS C400

Du får et 6K Full Frame kamera med RF mount.
Man kan købe et PL eller EF mount som option.

Du får en forbedret Dual Pixel auto fokus version II.
Kameraet optager på CFexpress 2.0 Type B eller SD V90 kort.

DYNAMIC RANGE 16 Stops (CANON LOG2)

MAX 60 FPS (6K)
MAX 120 FPS (4K)
MAX 180 FPS (Super 16mm crop 2K/FHD)

Der er indbygget ND og man kan vælge mellem 2/4/6/8/10 Stops.

Audio:

4 ch.
Kameraet kommer med 2  audio audiokanaler (Mini XLR i body) og man kan udvide med 2 audiokanaler ved at bruge Canon’s Multi-Functions shoe og TASCAM CA-XLR2D (option) audio adapter.

Du får On-body I/O som 12G-SDI, 3G-SDI, 2x mini-XLR, Mic In, Remote stik, Timecode, LENS stik, og Genlock / SYNC / Return.

Der er indbygget Wi-Fi / Ethernet der muliggøre real-time IP streaming (SRT / RTSP) og remote control via XC Protocol.



SPECIFIKATION:

Sensor:
Full Frame Back-Side Illuminated (bsi) Cmos Sensor

Sensor Size (effective Mp):
Approx. 19.05 Mp (6 K/4 K/2 K)
Approx. 17.86 Mp (4 K Uhd/fhd)

Recording Resolution:
6 K/4 K/4 K Uhd/2 K/fhd

Recording Format/data Rate (max):
Cinema Raw Light: 2.1 Gbps
Xf-Avc/mxf: 1.2 Gbps -  Xf-Avc S/mp4: 1.2 Gbps -  Xf-Hevc S/mp4: 225 Mbps

Dynamic Range:
16 Stops (canon Log2)

File Type:
Cinema Raw Light Lt/st/hq - Xf-Avc (mxf) -  Xf-Avc S / Xf-Hevc S (mp4)

Sampling/bit Depth:
Raw: 12-Bit -  Xf-Avc: All-I or Long Gop 4:2:2 10-Bit
Xf-Avc S: All-I or Long Gop 4:2:2 10-Bit  Xf-Hevc S: Long Gop 4:2:2 / 4:2:0 10-Bit  Proxy: Long Gop 4:2:0 8-Bit

Frame Rate (pal):
50p/50i/25p/24p

Max Frame Rate (pal):
Max 60 Fps (6 K) -  Max 120 Fps (4 K) -  Max 180 Fps (super 16mm Crop 2 K/fhd)

Recording Media:
CF express 2.0™ X1  SD Card X1

Timecode:
Yes

Genlock:
Yes, via Din1.0 / 2.3 (shared with Sync & Return)

Audio:
Raw / Xf-Avc : Linear Pcm  (24-Bit / 48 K Hz, 4 Channels)  Xf-Avc S / Xf-Hevc S : Linear Pcm  (24-Bit / 48 K Hz, 4 Channels) or Mpeg2-Aac Lc
(16 Bit 48k Hz) 2 Channels

Dual Pixel Cmos Af*:
Yes; Approx. 100% Horizontal and Vertical Range of Sensor Area

Built-In Nd Filters:
Yes, 2/4/6/8/10 Stops

Anamorphic Support:
Yes, 2.0x/1.8x/1.3x

Lens Mount:
Canon Rf Mount -  Pl Mount Support via Pl-Rf Mount Adapter
EF Mount Support via EF-Eos R Mount Adapter

Dimensions:
Approx. 142 X 135 X 135 Mm

Weight (body Only):
Approx. 1540g notes:

• Dual Pixel Cmos Af Not Available on Pl Mount
  Models or With Ef Mount Cinema Prime Lens Range

What's in the box?

• EOS C400 Body

• Handle Unit

• Camera Grip (incl. grip attachment ring)

• LCD Monitor & Attachment Unit

• MC-5U Monitor Cable

• Microphone Holder & Screws

• Body Cap

• Tape Measure Hook

• Hex Wrench

• BP-A60N Battery

• CG-A10 Battery Charger

• CA-CP300B Power Adapter

• User Manual
